产品特点
|
Description |
Specification |
|
Part number |
C8200-1N-4T and C8200L-1N-4T |
|
Dimensions (H x W x D) |
1.73 x 17.25 x 11.8 in. (4.39 x 43.81 x 29.97 cm) |
|
Rack Units (RU) |
1RU |
|
Chassis weight |
10 lb (4.54 kg) |
|
Input voltage |
AC: 90 to 264 VAC |
|
Operating temperature |
32° to 104°F (0° to 40°C) |
|
Storage temperature |
-40° to 150°F (-40° to 70°C) |
|
Acoustics, both models:
Sound pressure |
54 dBA/69 dBA |
|
Acoustics, both models:
Sound power |
68 dBA/80 dBA |
|
Relative humidity operating and nonoperating noncondensing |
Ambient (noncondensing) operating: 5% to 85% Ambient (noncondensing) nonoperating and storage: 5% to 95% |
|
Altitude |
0 to 10,000 feet (0 to 3050 meters) |
|
Mean Time Between Failures (MTBF) |
692,577 hours |
|
Product feature |
Benefits and description |
|
Multicore processors |
● C8200-1N-4T uses an 8-core CPU with 8 GB DRAM memory default
● C8200L-1N-4T uses a 4-core CPU with 4 GB DRAM memory default
● High-performance multicore processors support high-speed WAN connections
● Dynamic core allocation architecture will repurpose unused cores into forwarding entities as per the user’s configuration
|
|
Embedded IPsec VPN hardware acceleration |
● C8200-1N-4T enables up to 1 Gbps IPsec traffic
● C8200L-1N-4T enables up to 500 Mbps IPsec traffic
● Increases scalability for IPsec throughput requirements
● SSL and crypto hardware acceleration
|
|
Integrated Gigabit Ethernet ports |
● Provides four built-in Ethernet WAN ports
● Two Ethernet ports are Small Form-Factor Pluggable (SFP) and two are RJ45 ports, enabling fiber as well as copper connectivity
|
|
DRAM |
● C8200-1N-4T ships with 8 GB DRAM
● C8200L-1N-4T ships with 4 GB DRAM
● C8200-1N-4T can be upgraded to 16 GB and 32 GB DRAM for higher scale and performance
● C8200L-1N-4T can be upgraded to 8GB, 16 GB and 32 GB DRAM for higher scale and performance
|
|
Flash memory support |
● Both models have an integrated onboard 8-GB flash which is not upgradable. M.2 storage provides flash upgrade options
|
|
M.2 storage |
● The C8200-1N-4T is shipped with default 16G M.2 storage and can be upgraded to 32G M.2 USB and 600G M.2 Non-Volatile Memory Express (NVMe) Storage
● The C8200L-1N-4T does not ship with a default M.2 storage but can be upgraded to 16G, 32G USB and to 600G M.2 Non-Volatile Memory Express (NVMe) Storage
|
|
Power supply |
● Both models use an internal, fixed AC power supply
● Power over Ethernet (PoE) is available as an option
● PoE ports added in the Network Interface Module (NIM) slot will require an additional external PoE power supply
|
|
Modularity and form factor |
● 1-Rack Unit (1RU) form factor
● Supports NIM and Pluggable Interface Module (PIM) slots
|
|
Integrated security |
● Hardware-anchored Secure Boot and Secure Unique Device Identification (SUDI) support for Plug and Play to verify the identity of the hardware and software
|
优点和描述
|
Model |
Description |
1G port density |
Slots |
Memory (DRAM) default |
Storage (M.2 SSD) default |
|
C8200-1N-4T |
C8200 1RU w/ 1 NIM slot and 4x 1 Gigabit Ethernet WAN ports |
4 |
1 NIM 1 PIM |
8 GB |
16 GB |
|
C8200L-1N-4T |
C8200L 1RU w/ 1 NIM slot and 4x 1 Gigabit Ethernet WAN ports |
4 |
1 NIM 1 PIM |
4 GB |
No |
|
Feature |
C8200-1N-4T |
C8200L-1N-4T |
|
SD-WAN IPsec Throughput (1400Bytes) |
Up to 1Gbps |
Up to 500Mbps |
|
SD-WAN IPsec Throughput with IQDF** (1400Bytes) |
Up to 1Gbps |
Up to 460Mbps |
|
SD-WAN IPsec Throughput (IMIX*) |
900Mbps |
400Mbps |
|
SD-WAN IPsec Throughput with IQDF** (IMIX*) |
850Mbps |
300Mbps |
|
SD-WAN Overlay Tunnels scale |
2500 |
1500 |
|
Feature |
C8200-1N-4T |
C8200L-1N-4T |
|
IPv4 Forwarding Throughput (1400Bytes) |
Up to 3.8Gbps |
Up to 3.8Gbps |
|
IPsec Throughput (1400Bytes) |
Up to 1Gbps |
Up to 500Mbps |
|
IPsec Throughput (IMIX*) |
900Mbps |
400Mbps |
|
Feature |
C8200-1N-4T |
C8200L-1N-4T |
|
Number of IPsec SVTI Tunnels |
2500 |
1500 |
|
Number of ACLs per system |
4000 |
4000 |
|
Number of IPv4 ACEs per system |
72K |
72K |
|
Number of IPv4 Routes |
1.6M w/ default 8GB, up to 4M w/ 32GB |
800k w/ default 4GB, up to 4M w/ 32GB |
|
Number of IPv6 Routes |
1.5M w/ default 8GB, up to 4M w/ 32GB |
800k w/ default 4GB, up to 4M w/ 32GB |
|
Number of Queues |
8K |
8K |
|
Number of NAT Sessions |
1.2M w/ default 8GB, up to 2M w/ 32GB |
600k w/ default 4GB, up to 2M w/ 32GB |
|
Number of Firewall Sessions |
512K |
512K |
|
Number of VRFs |
4000 |
4000 |
订购信息
|
Product number |
Description |
|
Ethernet Layer 3 modules |
|
|
C-NIM-1M |
1-port 2.5/1Gbps RJ-45 WAN, 90W Poe 802.3 af/at/bt NIM |
|
C-NIM-2T |
2-port 100Mbps/1Gbps dual-mode RJ45/SFP, NIM with WAN MACSec |
|
LAN / LANWAN modules |
|
|
C-NIM-8T |
8-port 100Mbps/1Gbps switch NIM, LAN/WAN MACSec and Optional L3 |
|
C-NIM-8M* |
8-port 100M/1/2.5Gbps switch NIM, UPoE+, LAN/WAN MACSec and Optional L3 |
|
NIM-ES2-4 |
Cisco 4-port Gigabit Ethernet LAN switch NIM |
|
NIM-ES2-8 |
Cisco 8-port Gigabit Ethernet LAN switch NIM |
|
NIM-ES2-8-P |
Cisco 8-port Gigabit Ethernet LAN switch NIM with PoE support |
|
Voice modules |
|
|
NIM-2FXO |
2-port FXO NIM |
|
NIM-4FXO |
4-port FXO NIM |
|
NIM-2FXSP |
2-port FXS NIM |
|
NIM-4FXSP |
4-port FXS NIM |
|
NIM-2FXSP/4FXOP |
2-port FXS and 4-port FXO NIM |
|
NIM-4E/M |
4-port E/M NIM |
|
NIM-2BRI-NT/TE |
2-port BRI (NT and TE) NIM |
|
NIM-4BRI-NT/TE |
4-port BRI (NT and TE) NIM |
|
NIM-PVDM-32 |
32-channel Voice DSP NIM Module |
|
NIM-PVDM-64 |
64-channel Voice DSP NIM Module |
|
NIM-PVDM-128 |
128-channel Voice DSP NIM Module |
|
NIM-PVDM-256 |
256-channel Voice DSP NIM Module |
|
NIM-1MFT-T1/E1 |
1-port multiflex trunk voice/clear-channel data T1/E1 module |
|
NIM-2MFT-T1/E1 |
2-port multiflex trunk voice/clear-channel data T1/E1 module |
|
NIM-4MFT-T1/E1 |
4-port multiflex trunk voice/clear-channel data T1/E1 module |
|
NIM-8MFT-T1/E1 |
8-port multiflex trunk voice/clear-channel data T1/E1 module |
|
DSL/broadband |
|
|
NIM-VAB-A |
Multi-mode VDSL2/ADSL/2/2+ NIM Annex A |
|
NIM-VA-B |
Multi-mode VDSL2/ADSL/2/2+ NIM Annex B |
|
NIM-VAB-M |
Multi-mode VDSL2/ADSL/2/2+ NIM Annex M |
|
NIM-4SHDSL-EA |
Multi-mode G.SHDSL NIM |
|
ISDN BRI for Data |
|
|
NIM-2BRI-S/T |
2-port ISDN BRI WAN interface card for data |
|
NIM-4BRI-S/T |
4-port ISDN BRI WAN interface card for data |
|
Channelized T1/E1 and ISDN PRI |
|
|
NIM-1CE1T1-PRI |
1-port Multiflex trunk voice/channelized data T1/E1 module |
|
NIM-2CE1T1-PRI |
2-port Multiflex trunk voice/channelized data T1/E1 module |
|
NIM-8CE1T1-PRI |
8-port Multiflex trunk voice/channelized data T1/E1 module |
|
Serial WAN interface |
|
|
NIM-1T |
1-port serial high-speed WAN interface card |
|
NIM-2T |
2-port serial high-speed WAN interface card |
|
NIM-4T |
4-port serial high-speed WAN interface card |
|
Async WAN interface |
|
|
NIM-16A |
16-port Asynchronous Module |
|
NIM-24A |
24-port Asynchronous Module |
|
Wireless WAN (LTE) |
|
|
P-5GS6-R16SA-GL* |
5G Sub-6 GHz Pluggable – 5G SA Global |
|
P-5GS6-GL |
5G Sub-6 GHz Pluggable – Global |
|
P-LTEAP18-GL |
CAT18 LTE Advanced Pro Pluggable - Global |
|
P-LTEA7-NA* |
CAT7 LTE Advanced Pluggable - North America |
|
P-LTEA7-EAL* |
CAT7 LTE Advanced Pluggable - EMEA, APAC, and LATAM |
|
P-LTEA7-JP* |
CAT7 LTE Advanced Pluggable - Japan |
|
P-LTEA-EA |
CAT6 LTE Advanced Pluggable - North America and EMEA |
|
P-LTEA-LA |
CAT6 LTE Advanced Pluggable - APAC, ANZ, and LATAM |
|
NIM-LTEA-EA |
CAT6 LTE Advanced - North America and EMEA |
|
NIM-LTEA-LA |
CAT6 LTE Advanced - APAC, ANZ, and LATAM |
内存及配件
|
Product number |
Description |
|
MEM-C8200-8GB |
Cisco C8200 Edge Platform - 8 GB DRAM Memory |
|
MEM-C8200-16GB |
Cisco C8200 Edge Platform – 16 GB DRAM Memory |
|
MEM-C8200-32GB |
Cisco C8200 Edge Platform – 32 GB DRAM Memory |
|
M2USB-16G |
Cisco C8000 Edge Platform – 16 GB M.2 USB SSD Storage |
|
M2USB-32G |
Cisco C8000 Edge Platform – 32 GB M.2 USB SSD Storage |
|
SSD-M2SED-600G * |
Cisco C8000 Edge Platform – 600GB M.2 NVMe Self-Encrypted Drive (SED) Storage |
|
C8200-RM-19 |
Cisco C8200 1RU Edge Platform - Rack Mount kit - 19" |
|
C8200-RM-23 |
Cisco C8200 1RU Edge Platform - Rack Mount kit - 23" |
|
C8200-WM-1R |
Cisco C8200 1RU Edge Platform – Wall Mount Kit |
|
C8200-RFID-1R |
Cisco C8200 1RU Edge Platform - RFID |
|
C8200-NIM-BLANK |
Cisco C8200 NIM Blank |
|
C8200-PIM-BLANK |
Cisco C8200 PIM Blank |
